VMA-1240B 100V Media Amplifier

VMA1240-web1
VMA1240-web1VMA1240-web2VMA1240-web3VMA1240-web4VMA1240-web5VMA1240-web6VMA1240-web7

The VMA-1240B media amplifier combines a MP3 player, a Bluetooth receiver, a FM Tuner and a multitude of microphones and stereo sources with a high-headroom 240W high-impedance (100V)  amplifier in one compact unit. The amplifier is a transformer-less design using the unique Hybervolt™ topology, thus reducing the weight, improving audio fidelity and being field-serviceable. VCA volume remote control is provided for the main output. With the additional zone output, the unit can control an external amplifier for the zone signal, which can be the same as the master signal or a direct choice of inputs. A music on-hold output allows to feed the unit’s music program into a telephone system. Adding the seamless integration with fire evacuation systems, the VMA-1240B is the default choice for any mid-scale venue employing 100V line speakers for sound reinforcement.

  • Mixer section with 1x music and 3x microphone sources
  • Music source switchable: Media player/tuner, 3 external line inputs (with gain control) and front-side 3.5mm TRS line input
  • Internal media player/tuner with file/folder access for USB thumbdrives/SD cards up to 16GB/2000 songs, MP3 file name readout on large LCD display, regular and random play sequence, elapsed/remain time mode, FM tuner mode with RDS station display, jingle player with up to 3 jingles and additional scheduled play mode
  • Built-in Bluetooth receiver
  • Microphone inputs with phantom power, isolation transformer (only Mic 1), LPF & Gain (rear), volume & EQ controls (front) and on/off switch
  • Adjustable auto talk-over for automatic music level reduction
  • Master section with 2-Band EQ plus 5-LED output level meter
  • Additional rear-side maximum level control for master
  • Remote volume control option via external potentiometer
  • Chime sound generator with adjustable volume, external trigger and user-loadable sound on memory card
  • Zone section with separate volume control
  • Zone assignable to master signal or to two of the rear-side line inputs, routed to preamp output
  • Mono amplifier block with 240W@40 Ohms
  • Transformer-less Hybervolt™ amplification technology for extended bandwidth, lower weight and field-serviceability
  • Silent fan cooling with temperature controlled speed
  • Linear power supply with toroidal transformer
  • Phoenix-compatible speaker output with security cover
  • MOH (music on hold) output with adjustable music and mic levels, isolation transformer and selectable music source
  • Emergency priority input and output mute contact for external output muting/emergency message priority
  • Full metal case with detachable rack ears
  • AC mains voltage selector 115/230V
  • CE/ROHS compliant
  • Power (RMS): 1×240W @ 40 Ohms
  • Signal/Noise >72dBu (unweighted 22Hz-22KHz)
  • Crosstalk Damping >65dB
  • THD < 0.05%
  • Frequency response: 20Hz-20kHz
  • AC supply 115/230V~ 50Hz-60Hz (max. 320W)
  • Dimension W5xD237mm
  • Weight 8.6 kg

EMC/Safety Compliance:

  • EU safety: EN 60065:2001 +A1
  • EU EMC: EN55103-1:1997, EN55103-2: 1997
  • US safety: UL60065
  • US EMC: FCC Part 15

This product meets both the EMC Directive 2004/108/EC and the Low Voltage Directive 2006/95/EC.

Environmental Compliance:

  • This product is manufactured in accordance with EG directive 2002/95/EG of the European Union on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS).
  • This product does not contain more than 0.1% of weight of the SVHCs listed in annex XIV of the REACH regulation EC 1907/2006.
Datasheet
Picture archive

Hill VMA1240B (A) [115/230V-C14] SC
Order code: 2011401
GTIN13: 5060502921246
Size single carton: 535x350x180mm (0.0337 cbm)
Weight single carton: 9.6 kg
Units per master carton: 2
Size master carton: 560x390x375mm (0.0819 cbm)
Weight master carton: 20.4 kg

06-2017
